5.5.4 UNLOADING GENERATOR BUS
The generator bus load switch is automatically opened. To manually open the generator bus load
switch:
• Press the Auto Mode button. The module observes all Auto Mode start requests
and stopping timers before beginning the Auto Mode Stopping Sequence.
• Press the Manual Mode button followed by the Transfer to Mains button
• Press the Stop/Reset Mode button to open the generator bus load switch and remove
start request on MSC link.
• Activation of an auxiliary input that has been configured to Bus Load Inhibit
5.5.5 STOPPING SEQUENCE
The Return Delay timer operates to ensure that the starting request has been permanently removed
and isn’t just a short term removal. Should another start request be made during the Return Delay
period, the timer stops.
If there are no starting requests at the end of the Return Delay timer, the generator bus load switch
opens and the start request on the MSC link is removed.
