Maintenance, Spares, Repair & Servicing
057-259 ISSUE: 1 Page 142 of 146
10 MAINTENANCE, SPARES, REPAIR AND SERVICING
The controller is Fit and Forget. As such, there are no user serviceable parts within the controller.
In the case of malfunction, you should contact your original equipment manufacturer (OEM).
10.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE
If you require additional plugs from DSE, please contact our Sales department using the part numbers
below.
10.1.1 PACK OF PLUGS
DSE8660 MKII 007-891
10.1.2 INDIVIDUAL PLUGS
Module Terminal Designation
1 to 14
D+
W/L
14 way 5.08 mm 007-428
23 to 39
ECU MSC GOV AVR
17 way 5.08 mm 007-452
30 to 37
V1
8 way 7.62 mm 007-454
48to 51
V2
4 way 7.62 mm 007-171
52 to 58
7 way 5.08 mm 007-447
59 to 70
12 way 5.08 mm 007-109
71 to 76
RS485 Port 1 Port 2
6 way 5.08 mm 007-446
PC Configuration interface lead
(USB type A – USB type B)
016-125
10.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE
Item Description Part No.
Module Fixing Clips (Packet of 4) 020-294
