3.4.7 BUS AND LOAD CURRENT TRANSFORMER POSITION
NOTE: Bus/Load CT is NOT REQUIRED in a system including only one mains supply (with
one DSE8660 MKII controller). See section below detailing advantages of the Bus/Load CT in a
multiple mains (multiple DSE8x60) system.
NOTE: For further details of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite PC Software Manual.
3.4.7.1 3 PHASE, 4 WIRE WITH A BUS CURRENT TRANSFORMER
