4.2.5 ALARMS
When an alarm is active, the Internal Audible Alarm sounds and the Common Alarm LED, if
configured, illuminates.
The audible alarm is silenced by pressing the Alarm Mute / Lamp Test button.
The LCD display jumps from the ‘Information page’ to display the Alarm Page
1/2 Alarms
The LCD displays multiple alarms such as “Mains Over Voltage” and “Mains Reverse Power”. These
automatically scroll in the order that they occurred.
In the event of an alarm, the LCD displays the appropriate text. If an additional alarm then occurs, the
module displays the appropriate text.
Example:
1/2 Alarms
Electrical Trip
The type of alarm, e.g. Warning
The cause of alarm, e.g. Mains Failed to Close
Number of active alarms on Mains Alarms page.
This is alarm 1 of a total of 2 active alarms
The type of alarm, e.g. Warning
The cause of alarm, e.g. Mains Low Voltage
Number of active alarms on Bus Alarms page.
This is alarm 2 of a total of 2 active alarms
