5.2 STOP/RESET MODE
NOTE: If a digital input configured to Panel Lock is active on either module, changing
modes on both modules is not possible. Viewing the instruments and event logs is NOT
affected by panel lock.
NOTE: For further details of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite Software Manual.
Stop/Reset Mode is activated by pressing the Stop/Reset Mode button.
The LED above the Stop/Reset Mode button illuminates to indicate Stop/Reset Mode
operation.
In Stop/Reset Mode the module removes the generator bus from load (if necessary) before
removing the start request on the MSC Link.
When the Stop/Reset Mode , it is possible to send configuration files to the module from DSE
Configuration Suite PC software and to enter the Front Panel Editor to change parameters.
Any latched alarms that have been cleared are reset when Stop/Reset Mode is entered.
A start request is not sent on the MSC Link when in Stop/Reset Mode . If start signals are given,
they are ignored until Auto Mode is entered.
If Immediate Mains Dropout is enabled and the module is in Stop/Reset Mode , the mains load
switch is opened and closed as appropriate when the mains fails or becomes available to take load.
