Description of Controls
Page 77 of 146 057-259 ISSUE: 1
4.2.3.1 COMMISSIONING SCREENS
NOTE: Some of the items are removed from the commissioning screens if they are not
applicable to the module configuration.
Commissioning screens are available to both aid the commissioning process and also to give
additional information about the synchronising and load sharing process.
These screens are enabled and disabled in the module’s display editor.
Commissioning Screen 1
L – L 0 V kW 0.0 Mains average L-L V and total kW
Sets Ld 0
kVAr 0.0 Sets on load and total kvar
Ramp 0.0% kW 0.0% Ramp rate and percentage of full load kW
Pf ----- kVAr 0.0% Power factor and percentage of full load kW
Commissioning Screen 2
kW 0 kVAr 0
Actual kW and actual kVAr
BTgt 0% kW 0.0%
Bus target kW and actual kW percentage
BTgt 0% kVAr 0.0%
Bus target kVAr and actual kVAr percentage
Sets Ld 0 BV12 0V
Sets on load and bus average L1-L2 V
Commissioning Screen 3
MTgt 0% kW 0.0
Mains target kW and actual kW
BTgt 0% kVAr 0.0
Bus target kVAr and actual kVAr
Pf ----- L-L 0V
Power factor and mains average L-L V
Sets Ld 0 Amps 0A
Sets on Load and load average current
Commissioning Screen 4
NVb 0V NVm 0V
Nominal voltage bus and nominal voltage mains
AD 0V NAD 0V
Average difference and nominal average difference
MV12 0V BV12 0V
Mains average L1-L2 V and bus average L1-L2 V
SM12 0V Pha 0°
Scaled mains voltage L1-L2 V and phase angle
