4.3 USER CONFIGURABLE INDICATORS
These LEDs are configured by the user to indicate any one of
100+ different functions
based
around the following:-
Indications - Monitoring of a digital input and indicating associated functioning user’s equipment -
Such as Battery Charger On, etc.
Warnings & Electrical Trips - Specific indication of a particular warning or shutdown condition,
backed up by LCD indication - Such as Export Power Limit, R.O.C.O.F, etc.
Status Indications - Indication of specific functions or sequences derived from the modules operating
state - Such as System in Auto, Check Sync, Panel Locked, etc.
User configurable LEDs
