5.4.3 UNLOADING GENERATOR BUS (FROM CONTINUOUS PARALLEL)
The generator bus load switch is not automatically opened. To manually open the generator bus load
switch:
• Press the Manual Mode button followed by the Transfer to Mains button
• Press the Auto Mode button. The module observes all Auto Mode start requests
and stopping timers before beginning the Auto Mode Stopping Sequence.
• Press the Stop/Reset Mode button to open the generator bus load switch and remove
start request on MSC link.
• Activation of an auxiliary input that has been configured to Bus Load Inhibit
5.4.4 UNLOADING GENERATOR BUS (FROM ISLAND MODE)
The generator bus load switch is not automatically opened. To manually open the generator bus load
switch:
• Press the Manual Mode button followed by the Transfer to Mains button this puts
the generator bus in parallel with the mains, press the Transfer to Mains button to
unload the generator bus and transfer the load to the mains.
• Press the Auto Mode button. The module observes all Auto Mode start requests
and stopping timers before beginning the Auto Mode Stopping Sequence.
• Press the Stop/Reset Mode button to open the generator bus load switch and remove
start request on MSC link.
• Activation of an auxiliary input that has been configured to Bus Load Inhibit
5.4.5 STOPPING SEQUENCE
In Test Mode the set continues to run until either:
• The Stop/Reset Mode button is pressed – The generator bus load switch opens
immediately and start request on MSC link is removed.
• The Auto Mode button is pressed. The module observes all Auto Mode start
requests and stopping timers before beginning the Auto Mode Stopping Sequence.
