Deep Sea Electronics Plc DSE8660 MKII

Installation
Page 45 of 146 057-259 ISSUE: 1
3.2.7 DIGITAL INPUTS
NOTE: For further details of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite PC Software Manual.
Pin
No
Description
Cable
Size
Notes
59 Configurable Digital Input A
0.5 mm²
AWG 20
Switch To Negative
60 Configurable Digital Input B
0.5 mm²
AWG 20
Switch To Negative
61 Configurable Digital Input C
0.5 mm²
AWG 20
Switch To Negative
62 Configurable Digital Input D
0.5 mm²
AWG 20
Switch To Negative
63 Configurable Digital Input E
0.5 mm²
AWG 20
Switch To Negative
64 Configurable Digital Input F
0.5 mm²
AWG 20
Switch To Negative
65 Configurable Digital Input G
0.5 mm²
AWG 20
Switch To Negative
66 Configurable Digital Input H
0.5 mm²
AWG 20
Switch To Negative
67 Configurable Digital Input I
0.5 mm²
AWG 20
Switch To Negative
68 Configurable Digital Input J
0.5 mm²
AWG 20
Switch To Negative
69 Configurable Digital Input K
0.5 mm²
AWG 20
Switch To Negative
70 Configurable Digital Input L
0.5 mm²
AWG 20
Switch To Negative
