5.3 MANUAL MODE
NOTE: If a digital input configured to Panel Lock is active on either module, changing
modes on both modules is not possible. Viewing the instruments and event logs is NOT
affected by panel lock.
Manual Mode is activated by pressing the Manual Mode button.
The LED above the Manual Mode button illuminates to indicate Manual Mode operations.
In Manual Mode , a start request does not occur automatically.
To create a start request, press the Start button.
5.3.1 STARTING SEQUENCE
NOTE: There is no Start Delay in this mode of operation.
NOTE: For further details of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite Software Manual.
The starting sequence is controlled in the DSE8x10 module.
