5.7.3 TEST MODE
• Scheduled runs do not occur when the module is in Test Mode waiting for a start
request.
• If a scheduled run configured to ‘Island’ begins when the module is in Manual Mode ,
generator bus is available and in constant parallel, the generator bus is placed in island mode
operation.
5.7.4 AUTO MODE
• Scheduled runs operate only if the module is in Auto Mode with no Electrical Trip alarm
active.
• If the module is in Stop/Reset Mode or Manual Mode when a scheduled run begins,
the start request is not given. However, if the module is moved into Auto Mode during a
scheduled run, the start request is given.
• If a scheduled run configured to ‘Parallel’ or ‘Island’ begins when the when the module is in
Auto Mode , generator bus is available and off load the generator bus is placed on load.
• Depending upon configuration by the system designer, an external input can be used to
inhibit a scheduled run.
