2.10.4 ETHERNET PORT
The Ethernet port on the controller supports the Modbus TCP protocol and is for connection for up to
five Modbus master devices.
NOTE: For further details of module configuration, refer to DSE Publication: 057-238
DSE8610 MKII Configuration Suite PC Software Manual.
The DSE MODBUS register table for the controller is available upon request from the DSE Technical
Support Department.
Ethernet is used for point-to-point cable connection of more than one device and allows for
connection to PCs, PLCs and Building Management Systems (to name just a few devices).
One advantage of the Ethernet interface is the ability to interface into an existing LAN (Local Area
Network) connection for remote connection via an internet connection. This allows for a large distance
between the module and a PC running the DSE Configuration Suite software. The operator is then
able to control the module, starting or stopping the engine, selecting operating modes, etc.
The various operating parameters (such as coolant temperature, oil pressure, etc.) of the remote
engine are viewed or changed.
NOTE: For a single module to PC connection and distances up to 6 m (20 feet) the USB
connection method is more suitable and provides for a lower cost alternative to Ethernet
(which is more suited to longer distance connections).
NOTE: DSE stock 2 m (6.5 feet) Ethernet Cable, DSE Part Number: 016-137. Alternatively
they can be purchased from any PC or IT store.
