3.3 TYPICAL WIRING DIAGRAM (3 PHASE, 4 WIRE STAR)
NOTE: It is recommended NOT to fit UV coils on the mains breaker.
As every system has different requirements, these diagrams show only a typical system and do not
intend to show a complete system.
Genset manufacturers and panel builders may use these diagrams as a starting point; however
always refer to the completed system diagram provided by the system manufacturer for complete
wiring detail.
Further wiring suggestions are available in the following DSE publications, available at
www.deepseaplc.com to website members.
