4 DESCRIPTION OF CONTROLS
CAUTION: The module may instruct an engine start event due to external influences.
Therefore, it is possible for the engine to start at any time without warning. Prior to performing
any maintenance on the system, it is recommended that steps are taken to remove the battery
and isolate supplies.
NOTE: The following descriptions detail the sequences followed by a module containing
the standard ‘factory configuration’. Always refer to your configuration source for the exact
sequences and timers observed by any particular module in the field.
Control of the module is via push buttons mounted on the front of the module with
Stop/Reset Mode , Manual Mode ,
Test Mode
,
Auto Mode , Alarm Mute/Lamp
Test , Start , Transfer to Mains
and Transfer to Generator Bus functions. For
normal operation, these are the only controls which need to be operated. Details of their operation are
provided later in this document.
Menu
Navigation
Module
Display
Stop / Reset
