Protections
Page 117 of 146 057-259 ISSUE: 1
2131 ID 1 to 4 Analogue Input
A to J High
NOTE: Due to module configuration the alarm message
that appears on the display may be different. For further details
of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite PC Software Manual.
The module detected that an analogue input value of a DSE2131
had risen above the Flexible Sensor High Alarm Trip level.
2131 ID 1 to 4 Analogue Input
A to J Low
NOTE: Due to module configuration the alarm message
that appears on the display may be different. For further details
of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite PC Software Manual.
The module detected that an analogue input value of a DSE2131
had fallen below the Flexible Sensor Low Alarm Trip level.
2131 ID1 to 4 Digital Input
A to J
NOTE: Due to module configuration the alarm message
that appears on the display may be different. For further details
of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite PC Software Manual.
The module detected that a digital input configured to create a fault
condition on a DSE2131 expansion module became active and the
appropriate LCD message displayed.
2133 ID 1 to 4 Analogue Input
A to H High
NOTE: Due to module configuration the alarm message
that appears on the display may be different. For further details
of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite PC Software Manual.
The module detected that an analogue input value of a DSE2133
had risen above the Flexible Sensor High Alarm Trip level.
2133 ID 1 to 4 Analogue Input
A to H Low
NOTE: Due to module configuration the alarm message
that appears on the display may be different. For further details
of module configuration, refer to DSE Publication: 057-257
DSE8660 MKII Configuration Suite PC Software Manual.
The module detected that an analogue input value of a DSE2133
had fallen below the Flexible Sensor Low Alarm Trip level.
Bus Asymmetry High
The module detected the bus voltage asymmetry had risen above
the configurable Trip level for the configured delay timer.
Bus Failed To Close
If the bus breaker fails to close, the LCD indicate
Close.
Bus Failed To Open
If the bus breaker fails to open, the LCD indicates Bus Failed To
Open.
Bus Over Negative Sequence
The module detected the bus voltage negative sequence had risen
above the configurable Trip level for the configured delay timer.
Bus Over Zero Sequence
The module detected the bus voltage zero sequence had risen
above the configurable Trip level for the configured delay timer.
