Chapter 4 Parameters|
||
|
4-80 Revision 2016/03, 6ELE, V1.14
Content Address Function
Status
monitor
Read only
13: Reserved
14: PHL (Phase-Loss)
2100H 15: Reserved
16: Auto accel/decel failure (cFA)
17: Software protection enabled (codE)
18: Power Board CPU WRITE failure (CF1.0)
19: Power Board CPU READ failure (CF2.0)
20: CC, OC Hardware protection failure (HPF1)
21: OV Hardware protection failure (HPF2)
22: GFF Hardware protection failure (HPF3)
23: OC Hardware protection failure (HPF4)
24: U-phase error (cF3.0)
25: V-phase error (cF3.1)
26: W-phase error (cF3.2)
27: DCBUS error (cF3.3)
28: IGBT Overheat (cF3.4)
29: Reserved
30: Reserved
31: Reserved
32: ACI signal error (AErr)
33: Reserved
34: Motor PTC overheat protection (PtC1)
2101H
Status of AC drive
Bit 0-1
00B: RUN LED is off, STOP LED is on (The AC motor
Drive stops)
01B: RUN LED blinks, STOP LED is on (When AC
motor drive decelerates to stop)
10B: RUN LED is on, STOP LED blinks (When AC
motor drive is standby)
11B: RUN LED is on, STOP LED is off (When AC motor
drive runs)
Bit 2 1: JOG command
Bit 3-4 00B: FWD LED is on, REV LED is off (When AC motor
drive runs forward)
01B: FWD LED is on, REV LED blinks (When AC motor
drive runs from reverse to forward)
10B: FWD LED blinks, REV LED is on (When AC motor
drive runs from forward to reverse)
11B: FWD LED is off, REV LED is on (When AC motor
drive runs reverse)
Bit 5-7 Reserved
Bit 8
1: Master frequency Controlled by communication
interface
Bit 9 1: Master frequency controlled by analog signal
