Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
4-43
Group 3: Output Function Parameters
03.00
Multi-function Output Relay (RA1, RB1, RC1)
Factory Setting: 8
Settings Function Description
0
No Function
1 AC Drive Operational
Active when the drive is ready or RUN command is “ON”.
2 Master Frequency Attained
Active when the AC motor drive reaches the output frequency
setting.
3 Zero Speed
Active when Command Frequency is lower than the Minimum
Output Frequency.
4 Over-Torque Detection
Active as long as over-torque is detected. (Refer to Pr.06.03 ~
Pr.06.05)
5 Baseblock (B.B.) Indication
Active when the output of the AC motor drive is shut off during
baseblock. Base block can be forced by Multi-function input (setting
09).
6 Low-Voltage Indication
Active when low voltage(Lv) is detected.
7 Operation Mode Indication
Active when operation command is controlled by external terminal.
8 Fault Indication
Active when a fault occurs (oc, ov, oH1, oL, oL1, EF, cF3, HPF,
ocA, ocd, ocn, GFF).
9
Desired Frequency
Attained
Active when the desired frequency (Pr.03.02) is attained.
10
Terminal Count Value
Attained
Active when the counter reaches Terminal Count Value.
11
Preliminary Count Value
Attained
Active when the counter reaches Preliminary Count Value.
12
Over Voltage Stall
supervision
Active when the Over Voltage Stall function operating
13
Over Current Stall
supervision
Active when the Over Current Stall function operating
14
Heat Sink Overheat
Warning
When heatsink overheats, it will signal to prevent OH turn off the
drive. When it is higher than 85
o
C (185
o
F), it will be ON.
15 Over Voltage supervision
Active when the DC-BUS voltage exceeds level
16 PID supervision
Active when the PID feedback signal is abnormal (Refer to Pr.10.12
and Pr.13.)
17 Forward command
Active when the direction command is FWD
18 Reverse command
Active when the direction command is REV
19 Zero Speed Output Signal
Active when the drive is standby or stop
20
Communication Warning
(FbE,Cexx, AoL2, AUE,
SAvE)
Active when there is a Communication Warning
21
Brake Control (Desired
Frequency Attained)
Active when output frequency ≥Pr.03.11. Deactivated when output
frequency ≤Pr.03.12 after STOP command.
22 AC Motor Drive Ready
Active when AC motor drive is ready.
23
Multi-pump system error
display (only master)
If any error occurred on the inverter of the multi-pump system, the
RLY will be turned on
