Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14 A-1
Appendix A Specifications
There are 115V, 230V and 460V models in the VFD-EL series. For 115V models, it is 1-phase models. For 0.25 to
3HP of the 230V models, there are 1-phase/3-phase models. Refer to following specifications for details.
Voltage Class
115V Class
Model Number VFD-XXXEL 002 004 007
Max. Applicable Motor Output (kW) 0.2 0.4 0.75
Max. Applicable Motor Output (hp) 0.25 0.5 1.0
Output
Rating
Rated Output Capacity (kVA) 0.6 1.0 1.6
Rated Output Current (A) 1.6 2.5 4.2
Maximum Output Voltage (V) 3-Phase Proportional to Twice the Input Voltage
Output Frequency (Hz) 0.1~599 Hz
Carrier Frequency (kHz) 2-12
Input
Rating
Rated Input Current (A) 6.4 9 18
Rated Voltage/Frequency Single phase, 100-120V, 50/60Hz
Voltage Tolerance
±
10%(90~132 V)
Frequency Tolerance
±
5%(47~63 Hz)
Cooling Method Natural Cooling
Weight (kg) 1.1 1.1 1.4
Voltage Class 230V Class
Model Number VFD-XXXEL 002 004 007 015 022 037
Max. Applicable Motor Output (kW) 0.2 0.4 0.75 1.5 2.2 3.7
Max. Applicable Motor Output (hp) 0.25 0.5 1.0 2.0 3.0 5.0
Output
Rating
Rated Output Capacity (kVA) 0.6 1.0 1.6 2.9 4.2 6.5
Rated Output Current (A) 1.6 2.5 4.2 7.5 11.0 17
Maximum Output Voltage (V) 3-Phase Proportional to Input Voltage
Output Frequency (Hz) 0.1~599 Hz
Carrier Frequency (kHz) 2-12
Input Rating
XXXEL
21A
Rated Input Current
(A)
4.9 6.5 9.5 15.7 24 --
Rated
Voltage/Frequency
1-phase, 200-240 V, 50/60Hz
XXXEL
23A
Rated Input Current
(A)
1.9 2.7 4.9 9 15 20.6
Rated
Voltage/Frequency
3-phase, 200-240V, 50/60Hz
Voltage Tolerance
±
10%(180~264 V)
Frequency Tolerance
±
5%(47~63 Hz)
Cooling Method Natural Cooling Fan Cooling
Weight (kg) 1.2 1.2 1.2 1.7 1.7 1.7
Voltage Class 460V Class
Model Number VFD-XXXEL 004 007 015 022 037
Max. Applicable Motor Output (kW) 0.4 0.75 1.5 2.2 3.7
Max. Applicable Motor Output (hp) 0.5 1.0 2.0 3.0 5.0
Output
Rating
Rated Output Capacity (kVA) 1.2 2.0 3.3 4.4 6.8
Rated Output Current (A) 1.5 2.5 4.2 5.5 8.2
Maximum Output Voltage (V) 3-Phase Proportional to Input Voltage
Output Frequency (Hz) 0.1~599 Hz
Carrier Frequency (kHz) 2-12
Input
Rating
Rated Input Current (A) 1.8 3.2 4.3 7.1 9.0
Rated Voltage/Frequency 3-phase, 380-480V, 50/60Hz
Voltage Tolerance
±
10%(342~528V)
Frequency Tolerance
±
5%(47~63Hz)
Cooling Method Natural Cooling Fan Cooling
Weight (kg) 1.2 1.2 1.2 1.7 1.7
