4.3 Description of Parameter Settings
Group 0: User Parameters 

: This parameter can be set during operation.
00.00
Identity Code of the AC Motor Drive
Settings Read Only Factory setting: ##
00.01
Rated Current Display of the AC Motor Drive
Settings Read Only Factory setting: #.#
 Pr. 00.00 displays the identity code of the AC motor drive. The capacity, rated current, rated voltage and the
max. carrier frequency relate to the identity code. Users can use the following table to check how the rated
current, rated voltage and max. carrier frequency of the AC motor drive correspond to the identity code.
 Pr.00.01 displays the rated current of the AC motor drive. By reading this parameter the user can check if the
AC motor drive is correct.
115V/
230V Series
kW 0.2 0.4 0.75 1.5 2.2 3.7
HP 0.25 0.5 1.0 2.0 3.0 5.0
Pr.00-00 0 2 4 6 8 10
Rated Output Current (A) 1.6 2.5 4.2 7.5 11.0 17.0
Max. Carrier Frequency 12kHz

460
V Series
kW 0.4 0.75 1.5 2.2 3.7
HP 0.5 1.0 2.0 3.0 5.0
Pr.00-00 3 5 7 9 11
Rated Output Current (A) 1.5 2.5 4.2 5.5 8.2
Max. Carrier Frequency 12kHz
00.02
Parameter Reset
Factory Setting: 0
Settings 0 Parameter can be read/written
1 All parameters are read-only
8 Keypad lock
9 All parameters are reset to factory settings (50Hz, 230V/400V or 220V/380V depends
on Pr.00.12)
10 All parameters are reset to factory settings (60Hz, 115V/220V/440V)
 This parameter allows the user to reset all parameters to the factory settings except the fault records (Pr.06.08
~ Pr.06.12).
50Hz: Pr.01.00 and Pr.01.01 are set to 50Hz and Pr.01.02 will be set by Pr.00.12.
60Hz: Pr.01.00 and Pr.01.01 are set to 60Hz and Pr.01.02 is set to 115V, 230V or 460V.
 When Pr.00.02=1, all parameters are read-only. To write all parameters, set Pr.00.02=0.
00.03
Start-up Display Selection
Factory Setting: 0
Settings 0 Display the frequency command value (Fxxx)
1 Display the actual output frequency (Hxxx)
2 Display the output current in A supplied to the motor (Axxx)
3 Display the content of user-defined unit (Uxxx)
4 FWD/REV command
 This parameter determines the start-up display page after power is applied to the drive.
