Delta Electronics VFD-EL series - B.2 no Fuse Circuit Breaker Chart

Revision 2016/03, 6ELE, V1.14
B-5
B.2 No Fuse Circuit Breaker Chart
For 1-phase/3-phase drives, the current rating of the breaker shall be within 2-4 times rated input current.
1-phase 3-phase
Model
Recommended no-fuse
breaker (A)
Model
Recommended no-fuse
breaker (A)
VFD002EL11A 15 VFD002EL23A 5
VFD002EL21A 10 VFD004EL23A 5
VFD004EL11A 20 VFD004EL43A 5
VFD004EL21A 15 VFD007EL23A 10
VFD007EL11A 30 VFD007EL43A 5
VFD007EL21A 20 VFD015EL23A 20
VFD015EL21A 30 VFD015EL43A 10
VFD022EL21A 50 VFD022EL23A 30
VFD022EL43A 15
VFD037EL23A 40
VFD037EL43A 20
