Chapter 4 Parameters|
||
|
4-10 Revision 2016/03, 6ELE, V1.14
Group 4 Input Function Parameters
Parameter
Function Setting
Factory
Setting
Custome
r
04.00 Keypad Potentiometer Bias 0.0 to 100.0 % 0.0
04.01 Keypad Potentiometer Bias Polarity
0: Positive bias
1: Negative bias
00
04.02 Keypad Potentiometer Gain 0.1 to 200.0 % 100.0
04.03
Keypad Potentiometer Negative Bias,
Reverse Motion Enable/Disable
0: No negative bias command
0
1: Negative bias: REV motion enabled
04.04 2-wire/3-wire Operation Control Modes 0: 2-wire: FWD/STOP, REV/STOP
0
1: 2-wire: FWD/REV, RUN/STOP
2: 3-wire operation
04.05 Multi-function Input Terminal (MI3)
0: No function
1
1: Multi-Step speed command 1
2: Multi-Step speed command 2
04.06 Multi-function Input Terminal (MI4) 3: Multi-Step speed command 3 2
4: Multi-Step speed command 4
5: External reset
04.07 Multi-function Input Terminal (MI5) 6: Accel/Decel inhibit 3
7: Accel/Decel time selection
command
8: Jog Operation
04.08 Multi-function Input Terminal (MI6) 9: External base block 4
10: Up: Increment master frequency
11: Down: Decrement master
frequency
12: Counter Trigger Signal
13: Counter reset
14: E.F. External Fault Input
15: PID function disabled
16: Output shutoff stop
17: Parameter lock enable
18: Operation command selection
(external terminals)
19: Operation command
selection(keypad)
20: Operation command
selection(communication)
21: FWD/REV command
22: Source of second frequency
command
23 Simple position stop by forward
limit
24 Simple position stop by reverse
limit
25 Multi-pumps switch by Hand / Auto
mode.
