Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
4-11
Parameter
Function Setting
Factory
Setting
Custome
r
04.09 Multi-function Input Contact Selection
Bit0:MI1
Bit1:MI2
Bit2:MI3
Bit3:MI4
Bit4:MI5
Bit5:MI6
0:N.O., 1:N.C.
P.S.:MI1 to MI3 will be invalid when it
is 3-wire control.
0
04.10 Digital Terminal Input Debouncing Time 1 to 20 (*2ms) 1
04.11
Min AVI Voltage 0.00 to 10.00V
0.00
04.12
Min AVI Frequency
0.00 to 100.00% Fmax
0.00
04.13
Max AVI Voltage 0.00 to 10.00V
10.00
04.14
Max AVI Frequency 0.0 to 100.0% Fmax
100.0
04.15
Min ACI Current 0.0 to 20.0mA
4.0
04.16
Min ACI Frequency
0.0 to 100.0% Fmax
0.0
04.17
Max ACI Current 0.0 to 20.0mA
20.0
04.18
Max ACI Frequency 0.0 to 100.0% Fmax
100.0
04.19
|
04.25
Reserved
04.26
Display the Status of Multi-
function Input
Terminal
Read only.
##
Bit0: MI1 Status
Bit1: MI2 Status
Bit2: MI3 Status
Bit3: MI4 Status
Bit4: MI5 Status
Bit5: MI6 Status
04.27
Internal/External Multi-function Input
Terminals Selection
0~4095
0
04.28
Internal Terminal Status
0~4095
0
