Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
4-33
Settings 0.00 ~
599.00Hz Factory Setting: 5.00
01.22
Simple Positioning Stop Frequency 2 Unit: 0.01
Settings 0.00 ~599.00Hz Factory Setting: 10.00
01.23
Simple Positioning Stop Frequency 3 Unit: 0.01
Settings 0.00 ~599.00Hz Factory Setting: 20.0
0
01.24
Simple Positioning Stop Frequency 4 Unit: 0.01
Settings 0.00 ~599.00Hz Factory Setting: 30.00
01.25
Simple Positioning Stop Frequency 5 Unit: 0.01
Settings 0.00 ~599.00Hz Factory Setting: 40.00
01.26
Simple Positioning Stop Frequency 6 Unit: 0.01
Settings 0.00 ~599.00Hz Factory Setting: 50.00
01.27
Simple Positioning Stop Frequency 7 Unit: 0.01
Settings 0.00 ~599.00Hz Factory Setting: 60.00
 The setting of Pr01-20~Pr01-27 has to follow the description below:
Pr01-20 ≦ Pr01- ≦ 21 Pr01- ≦ 22 Pr01- ≦ 23 Pr01- ≦ 24 Pr01- ≦ 25 Pr01- ≦ 26 Pr01-27
 If any of two parameters (between Pr01.20 ~ Pr01.27) have the same stop frequency, their Delay Time of Simple
Positioning Stop have to be the same as well.
01.28
Delay Time of Simple Positioning Stop 0 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.0
0
01.29
Delay Time of Simple Positioning Stop 1 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.00
01.30
Delay Time of Simple Positioning Stop 2 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.00
01.31
Delay Time of Simple Positioning Stop 3 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.0
0
01.32
Delay Time of Simple Positioning Stop 4 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.00
01.33
Delay Time of Simple Positioning Stop 5 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.00
01.34
Delay Time of Simple Positioning Stop 6 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.00
01.35
Delay Time of Simple Positioning Stop 7 Unit: 0.01
Settings 0.00 ~600.00 sec Factory Setting: 0.00
 Set Pr02.02 as [#4: Simple Positioning Stop; E.F.: coast to stop], before setting up Pr01.20 ~ Pr01.35.
 The settings of Pr01.20~Pr01.27 have to correspond to the settings of Pr01.28 ~Pr01.35. Corresponding
parameters :
(Pr01.20, Pr01.28)
(Pr01.21, Pr01.29)
(Pr01.22, Pr01.30)
(Pr01.23, Pr01.31)
(Pr01.24, Pr01.32)
(Pr01.25, Pr01.33)
(Pr01.26, Pr01.34)
(Pr01.27, Pr01.35)
 The function of Pr01.28~Pr01.35 is simple positioning. Speed will start to decelerate after the time set at
Pr01.28~Pr01.35 elapse. The accuracy of positioning is self-assessed by user.
