Chapter 4 Parameters|
||
|
4-8 Revision 2016/03, 6ELE, V1.14
Group 3 Output Function Parameters
Parameter
Function Setting
Factory
Setting
Custome
r
03.00
Multi-function Output
Relay (RA1, RB1, RC1)
0: No function 8
1: AC drive operational
2: Master frequency attained
3: Zero speed
4: Over torque detection
5: Base-Block (B.B.) indication
6: Low-voltage indication
7: Operation mode indication
8: Fault indication
9: Desired frequency attained
10: Terminal count value attained
11: Preliminary count value attained
12: Over Voltage Stall supervision
13: Over Current Stall supervision
14: Heat sink overheat warning
15: Over Voltage supervision
16: PID supervision
17: Forward command
18: Reverse command
19: Zero speed output signal
20: Warning(FbE,Cexx, AoL2, AUE, SAvE)
21: Brake control (Desired frequency attained)
22: AC motor drive ready
23: Multi-pump system error display (only master)
03.01 Reserved
03.02 Desired Frequency
Attained
0.00 to 599.0Hz 0.00
03.03
Analog Output Signal
Selection (AFM)
0: Analog frequency meter
0
1: Analog current meter
03.04 Analog Output Gain 1 to 200% 100
03.05 Terminal Count Value 0 to 9999 0
03.06 Preliminary Count Value
0 to 9999 0
03.07
EF Active When
Terminal Count Value
Attained
0: Terminal count value attained, no EF display
0
1: Terminal count value attained, EF active
03.08 Cooling Fan Control
0: Fan always ON
0
1: 1 minute after AC motor drive stops, fan will be OFF
2: Fan ON when AC motor drive runs, fan OFF when
AC motor drive stops
3: Fan ON when preliminary heatsink temperature
attained
4: Fan ON when AC motor drive runs, fan OFF when
AC motor drive stops. Fan is at standby mode when
AC is at 0Hz.
