Delta Electronics VFD-EL series - Page 36

Revision 2016/03, 6ELE, V1.14
4-7
Parameter
Function Setting
Factory
Setting
Customer
02.08
Accel/Decel Rate of Change of
UP/DOWN Operation with
Constant Speed
0.01~10.00 Hz 0.01
02.09
Source of Second Frequency
Command
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN. Last used frequency
saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI
3: RS-485 (RJ-45) communication
4: Digital keypad potentiometer
0
02.10
Combination of the First and
Second Master Frequency
Command
0: First Master Frequency Command
1: First Master Frequency Command+ Second
Master Frequency Command
2: First Master Frequency Command - Second
Master Frequency Command
0
02.11 Keypad Frequency Command
0.00 to 599.0Hz
60.00
02.12
Communication Frequency
Command
0.00 to 599.0Hz
60.00
02.13
The Selections for Saving
Keypad or Communication
Frequency Command
0: Save Keypad & Communication Frequency
0
1: Save Keypad Frequency only
2: Save Communication Frequency only
02.14
Initial Frequency Selection (for
keypad & RS485)
0: by Current Freq Command
0 1: by Zero Freq Command
2: by Frequency Display at Stop
02.15
Initial Frequency Setpoint (for
keypad & RS485)
0.00 ~ 599.0Hz 60.00
02.16
Display the Master Freq
Command Source
Read Only
Bit0=1: by First Freq Source (Pr.02.00)
Bit1=1: by Second Freq Source (Pr.02.09)
Bit2=1: by Multi-input function
##
02.17
Display the Operation
Command Source
Read Only
Bit0=1: by Digital Keypad
Bit1=1: by RS485 communication
Bit2=1: by External Terminal 2/3 wire mode
Bit3=1: by Multi-input function
##
02.18 User-defined Value 2 Setting 0 to Pr.00.13 0
02.19 User-defined Value 2 0 to 9999 ##
