3.5 Address list
The contents of available addresses are shown as below:
Content Address Function
AC drive
Parameters
GGnnH
GG means parameter group, nn means parameter number, for
example, the address of Pr 04.01 is 0401H. Refer to chapter 5 for the
function of each parameter. When reading parameter by command
code 03H, only one parameter can be read at one time.
Command
Write only
2000H
Bit 0-1
00B: No function
01B: Stop
10B: Run
11B: Jog + Run
Bit 2-3 Reserved
Bit 4-5
00B: No function
01B: FWD
10B: REV
11B: Change direction
Bit 6-7
00B: Comm. forced 1st accel/decel
01B: Comm. forced 2nd accel/decel
Bit 8-15 Reserved
2001H Frequency command
2002H
Bit 0 1: EF (external fault) on
Bit 1 1: Reset
Bit 2-15 Reserved
Status
monitor
Read only
2100H
Error code:
0: No error occurred
1: Over-current (oc)
2: Over-voltage (ov)
3: IGBT Overheat (oH1)
4: Reserved
5: Overload (oL)
6: Overload1 (oL1)
7: Overload2 (oL2)
8: External fault (EF)
9: Current exceeds 2 times rated current during accel (ocA)
10: Current exceeds 2 times rated current during decel (ocd)
11: Current exceeds 2 times rated current during steady state
operation (ocn)
12: Ground Fault (GFF)
