Group 2: Operation Method Parameters
02.00
Source of First Master Frequency Command
Factory Setting: 1
02.09
Source of Second Master Frequency Command
Factory Setting: 0
Settings 0 Digital keypad UP/DOWN keys or Multi-function Inputs UP/DOWN. Last used
frequency saved. (Digital keypad is optional)
1 0 to +10V from AVI
2 4 to 20mA from ACI
3 RS-485 (RJ-45) communication
4 Digital keypad potentiometer
These parameters set the Master Frequency Command Source of the AC motor drive.
The factory setting for master frequency command is 1. (digital keypad is optional.)
Setting 2: use the ACI/AVI switch on the AC motor drive to select ACI or AVI.
When the AC motor drive is controlled by external terminal, please refer to Pr.02.05 for details.
The first /second frequency/operation command is enabled/disabled by Multi Function Input Terminals.
Please refer to Pr.04.05 ~ 04.08.
02.01
Source of First Operation Command
Factory Setting: 1
Settings 0 Digital keypad (Digital keypad is optional)
1 External terminals. Keypad STOP/RESET enabled.
2 External terminals. Keypad STOP/RESET disabled.
3 RS-485 (RJ-45)/USB communication. Keypad STOP/RESET enabled.
4 RS-485 (RJ-45)/USB communication. Keypad STOP/RESET disabled.
The factory setting for source of first operation command is 1. (digital keypad is optional.)
When the AC motor drive is controlled by external terminal, please refer to Pr.02.05/Pr.04.04 for details.
02.10
Combination of the First and Second Master Frequency Command
Factory Setting: 0
Settings 0 First Master Frequency Command Only
1 First Master Frequency + Second Master Frequency
2 First Master Frequency - Second Master Frequency
02.02
Stop Method
Factory Setting: 0
Settings 0 STOP: ramp to stop E.F.: coast to stop
1 STOP: coast to stop E.F.: coast to stop
2 STOP: ramp to stop E.F.: ramp to stop
3 STOP: coast to stop E.F.: ramp to stop
4 Simple positioning stop E.F.: coast to stoip
The parameter determines how the motor is stopped when the AC motor drive receives a valid stop command
or detects External Fault.
Ramp: the AC motor drive decelerates to Minimum Output Frequency (Pr.01.05) according to the deceleration
time and then stops.
Coast: the AC motor drive stops the output instantly upon command, and the motor free runs until it comes to a
complete standstill.
