Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
B-13
B.8 Fieldbus Modules
B.8.1 DeviceNet Communication Module (CME-DN01)
B.8.1.1 Panel Appearance and Dimensions
1. For RS-485 connection to VFD-EL 2. Communication port for connecting DeviceNet network 3. Address
selector 4. Baud rate selector 5. Three LED status indicators for monitor. (Refer to the figure below)
72.2 [2.84]
5
7
.
3
[
2
.
2
6
]
14.3 [0.57]
5
9
.
7
[
2
.
3
5
]
3.5 [0.14]
35.8 [1.41]
CME-DN 01
ADD1 A D D2
SP
500K
250K
125K
BA UD
MODNET
UNIT: mm(inch)
1
5
43
2
B.8.1.2 Wiring and Settings
Refer to following diagram for details.
CME-DN0 1
AD D1 AD D2
SP
500K
250K
125K
BAUD
MOD
NET
MAC address
Date Rate
CAN-L
V+
Empty
Pin
CAN-H
V-
1: Reserved
2: EV
5: SG+
6: Reserved
7: Reserved
8: Reserved
3: GND
4: SG-
Setting baud rate
BAUD
0
Switch
Value
Baud
Rate
0 125K
1 250K
2 500K
Other AUTO
Setting MAC addresses:
use decimal system.
ADD1
ADD2
