Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
B-6
B.3 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Model
I (A)
Input
I (A)
Output
Line Fuse
I (A) Bussmann P/N
VFD002EL11A 6.4 1.6 15 JJN-15
VFD002EL21A 4.9 1.6 10 JJN-10
VFD002EL23A 1.9 1.6 5 JJN-6
VFD004EL11A 9 2.5 20 JJN-20
VFD004EL21A 6.5 2.5 15 JJN-15
VFD004EL23A 2.7 2.5 5 JJN-6
VFD004EL43A 1.8 1.5 5 JJS-6
VFD007EL11A 18 4.2 30 JJN-30
VFD007EL21A 9.3 4.2 20 JJN-20
VFD007EL23A 4.9 4.2 10 JJN-10
VFD007EL43A 3.2 2.5 5 JJS-6
VFD015EL21A 15.7 7.5 30 JJN-30
VFD015EL23A 9 7.5 20 JJN-20
VFD015EL43A 4.3 4.2 10 JJS-10
VFD022EL21A 24 11 50 JJN-50
VFD022EL23A 15 11 30 JJN-30
VFD022EL43A 7.1 5.5 15 JJS-15
VFD037EL23A 20.6 17 40 JJN-40
VFD037EL43A 9.0 8.2 20 JJS-20
