Delta Electronics VFD-EL series User Manual

Chapter 4 Parameters|
||
|
4-54 Revision 2016/03, 6ELE, V1.14
Wiring of the pressure sensor:
Connect pressure sensor to +10V and AVI, then switch the SW2 switch to ACI
Hand & Auto mode:
(1) If any error occurred to the pressure sensor, the operation can be switched to be hand mode. That means
the operation is controlled by stand-alone system (RUN/STOP)
(2) When under auto mode control, only the master pump cab perform operating control.
(3) When under auto mode control, the slave pumps can be stopped while the motor drive is performing multi-
pump control. If then a run command is given to the slave pump, it will be controlled by the master pump.
04.09
Multi-function Input Contact Selection
Unit: 1
Settings 0 to 4095 Factory Setting: 0
 This parameter can be used to set the status of multi-function terminals (MI1~MI6 (N.O./N.C.) for standard AC
motor drive).
 The MI1~MI3 setting will be invalid when the operation command source is external terminal (2/3wire).
12345
0
0=N.O
1=N.C
MI1
MI2
MI3
MI4
MI5
MI6
Weights
Bit
 The Setting method: It needs to convert binary number (6-bit) to decimal number for input.
 For example: if setting MI3, MI5, MI6 to be N.C. and MI1, MI2, MI4 to be N.O. The setting value Pr.04.09
should be bit5X2
5
+bit4X2
4
+bit2X2
2
= 1X2
5
+1X2
4
+1X2
2
= 32+16+4=52 as shown in the following.
01011 0
Weights
Bit
0=N.O
1=N.C
MI1
MI2
MI3
MI4
MI5
MI6
The setting value
= bit5x2 +bit4x2 +bit2x2
5 4 2
= 1x2 +1x2 +1x2
5 4 2
=32+16+4
Setting 04.09
=52
NOTE:
2 =16384 2 =8192 2 =4096 2 =2048 2 =1024
2 =512 2 =256 2 =128 2 =64 2 =32
2 =16 2 =8 2 =4 2 =2 2 =1
14 13 12 11 10
9 8 7 6 5
4 3 2 1 0
04.10
Digital Terminal Input Debouncing Time
Unit: 2 msec
Settings
1 to 20
Factory Setting: 1
