Group 7 Motor Parameters
Parameter
Explanation Settings
Factory
Setting
Custome
r
07.00 Motor Rated Current 30 %FLA to 120% FLA FLA
07.01 Motor No-Load Current 0%FLA to 99% FLA 0.4*FLA
07.02 Torque Compensation 0.0 to 10.0 0.0
07.03 Slip Compensation Gain 0.00 to 10.00 0.00
07.04 Motor Parameters Auto Tuning 0: Disable
1: Auto-tuning R1 (Motor doesn’t run)
2: Auto-tuning R1 + No-load current(with
running motor)
0
07.05 Motor Line-to-Line Resistance R1
(Motor 0)
0~65535mΩ
0
07.06 Motor Rated Slip(Motor 0) 0.00~20.00Hz 3.00
07.07 Slip Compensation Limit 0~250% 200
07.08 Torque Compensation Time
Constant
0.01~10.00 sec 0.30
07.09 Slip
Compensation Time Constant
0.05~10.00 sec 0.20
07.10
Accumulative Motor Operation
Time (Min.)
0 to 1439 Min. 0
07.11
Accumulative Motor Operation
Time (Day)
0 to 65535 Day 0
07.12 Motor PTC Overheat Protection
0: Disable
1: Enable
0
07.13
Input Debouncing Time of the PTC
Protection
0~9999(*2ms) 100
07.14
Motor PTC Overheat Protection
Level
0.1~10.0V 2.4
07.15
Motor PTC Overheat Warning
Level
0.1~10.0V 1.2
07.16
Motor PTC Overheat Reset Delta
Level
0.1~5.0V 0.6
07.17
Treatment of the Motor PTC
Overheat
0: Warn and RAMP to stop
1: Warn and COAST to stop
2: Warn and keep running
0
