Revision 2016/03, 6ELE, V1.14
4-41
02.13
The Selections for Saving Keypad or Communication Frequency Command
Factory Setting: 0
Settings 0 Save Keypad & Communication Frequency
1 Save Keypad Frequency only
2 Save Communication Frequency only
This parameter is used to save keypad or RS-485 frequency command.
02.14
Initial Frequency Selection (for keypad & RS485)
Factory Setting: 0
Settings 0 By Current Freq Command
1 By Zero Freq Command
2 By Frequency Display at Stop
02.15
Initial Frequency Setpoint (for keypad & RS485) Unit: 0.01
Settings 0.00 ~ 599.00Hz Factory Setting: 60.00
These parameters are used to determinate the frequency at stop:
When setting Pr.02.14 to 0: the initial frequency will be current frequency.
When setting Pr.02.14 to 1: the initial frequency will be 0.
When setting Pr.02.14 to 2: the initial frequency will be Pr.02.15.
02.16 Display the Master Freq Command Source
Settings Read Only Factory setting: ##
You can read the master frequency command source by this parameter.
Display Value
Bit Function
1 Bit0=1 Master Freq Command Source by First Freq Source (Pr.02.00).
2 Bit1=1 Master Freq Command Source by Second Freq Source (Pr.02.09).
4 Bit2=1 Master Freq Command Source by Multi-input function
02.17 Display the Operation Command Source
Settings Read Only Factory setting: ##
You can read the operation source by this parameter.
Display Value
Bit Function
1 Bit0=1 Operation Command Source by Digital Keypad
2 Bit1=1 Operation Command Source by RS485 communication
4 Bit2=1 Operation Command Source by External Terminal
8 Bit3=1 Operation Command Source by Multi-input function
02.18 User-defined Value 2 Setting Unit: 1
Settings 0 to Pr.00.13 Factory Setting: 0
Use this parameter to change frequency when (1) Pr.00.13 is not set to 0 and frequency source is from
communication or (2) Pr.02.10 is not set to 0.
02.19 User-defined Value 2 Unit: 1
Settings Read-only Factory Setting: 0
