B.4 AC Reactor
B.4.1 AC Input Reactor Recommended Value
230V, 50/60Hz, 1-Phase
kW HP
Fundamental
Amps
Max.
continuous
Amps
Inductance (mH)
3~5% impedance
0.2 1/4 4 6 6.5
0.4 1/2 5 7.5 3
0.75 1 8 12 1.5
1.5 2 12 18 1.25
2.2 3 18 27 0.8
460V, 50/60Hz, 3-Phase
kW HP
Fundamental
Amps
Max.
continuous
Amps
Inductance (mH)
3%
impedance
5%
impedance
0.4 1/2 2 3 20 32
0.75 1 4 6 9 12
1.5 2 4 6 6.5 9
2.2 3 8 12 5 7.5
3.7 5 8 12 3 5
B.4.2 AC Output Reactor Recommended Value
115V/230V, 50/60Hz, 3-Phase
kW HP
Fundamental
Amps
Max.
con
tinuous
Amps
Inductance (mH)
3%
impedance
5%
impedance
0.2 1/4 4 4 9 12
0.4 1/2 6 6 6.5 9
0.75 1 8 12 3 5
1.5 2 8 12 1.5 3
2.2 3 12 18 1.25 2.5
3.7 5 18 27 0.8 1.5
460V, 50/60Hz, 3-Phase
kW HP
Fundamental
Amps
Max.
continuous
Amps
Inductance (mH)
3%
impedance
5%
impedance
0.4 1/2 2 3 20 32
0.75 1 4 6 9 12
1.5
2
4 6 6.5 9
2.2
3
8 12 5 7.5
3.7
5
12 18 2.5 4.2
