Revision 2016/03, 6ELE, V1.14
B-21
LED Descriptions
State Description
LED ON Constantly on
LED OFF Constantly off
LED
blinking
Flash, on for 0.2s and off for 0.2s
LED single
flash
On for 0.2s and off for 1s
LED
double
flash
On for 0.2s off for 0.2s, on for 0.2s and off for 1s
B.9 MKE-EP & DIN Rail
B.9.1 MKE-EP
EMC earthing plate for Shielding Cable
C CLAMP
TWO HOLE
STRAP 1
TWO HOLE
STRAP 2
