Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
B-18
B.8.4 CME-COP01 (CANopen)
CME-COP01 CANopen communication module is specifically for connecting to CANopen communication
module of Delta VFD-EL AC motor drive.
B.8.4.1 Product Profile
1
2
7 6 3 4 5
Unit: mm

COM port

CANopen connection port

RUN indicator

ERROR indicator

SP (Scan Port) indicator

Baud rate switch

Address switch
B.8.4.2 Specifications
CANopen Connection
Interface Pluggable connector (5.08mm)
Transmission
method
CAN
Transmission
cable
2-wire twisted shielded cable
Electrical
isolation
500V DC
Communication
Message
type
Process Data
Objects (PDO)
Bau
d
rate
10 Kbps
20 Kbps
50 Kbps
125 Kbps
250 Kbps
500 Kbps
800 Kbps
1 Mbps
Service Data
Object (SDO)
Synchronization
(SYNC)
Emergency
(EMCY)
Network
Management
(NMT)
Product
code
Delta VFD-EL AC motor drive 22
Device
type
402
Vendor ID 477
