Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
4-95
Related Parameters when Pr10.35=1
Parameter Function Setting
Factory
Setting
End
user’s
master
End
user’s
slave
Note
01.00
Maximum
Output
Frequency
(Fmax)
50.00 to 599.0 Hz 60.00 60.00 60.00
01.01
Maximum
Voltage
Frequency
(Fbase)
0.10 to 599.0 Hz 60.00
60.00 60.00 The setting
follows the
specifications
of pumps
01.02
Maximum
Output Voltage
(Vmax)
115V/230V series: 0.1V to 255.0V 220.0 220.0 220.0
460V series: 0.1V to 510.0V 440.0
 01.09 Accel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec
10.0
0.5 0.5 Defined by
user
 01.10 Decel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0 5.0 5.0
 01.12 Decel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec
10.0 3.0- 3.0
The elapsed
deceleration
time before the
inverter stops
when the
pressure
reaches the
setting value.
Parameter Function Setting
Factory
Setting
End
user’s
master
End
user’s
slave
Note
 02.00
Source of First
Master Frequency
Command
0: Digital keypad UP/DOWN keys or
Multi-function Inputs UP/DOWN. Last
used frequency saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI
3: RS-485 (RJ-45) communication
4: Digital keypad potentiometer
0 2 2
User
defined
 02.01
Source of First
Operation
Command
0: Digital keypad
0 0 0
User
defined
1: External terminals. Keypad
STOP/RESET enabled.
2: External terminals. Keypad
STOP/RESET disabled.
3: RS-485 (RJ-45) communication.
Keypad STOP/RESET enabled.
4: RS-485 (RJ-45) communication.
Keypad STOP/RESET disabled.
