Delta Electronics VFD-EL series User Manual

Revision 2016/03, 6ELE, V1.14
4-101
Parameter
Function Setting
Factor
y
Setting
End
user’s
master
End
user’s
slave
Note
01.00
Maximum Output
Frequency (Fmax)
50.00 to 599.0 Hz 60.00
60.00 60.00
01.01
Maximum Voltage
Frequency
(Fbase)
0.10 to 599.0 Hz 60.00
60.00 60.00 The setting
follows the
specifications
of pumps
01.02
Maximum Output
Voltage (Vmax)
115V/230V series: 0.1V to 255.0V 220.0 220.0 220.0
460V series: 0.1V to 510.0V 440.0
01.09 Accel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec
10.0
0.5 0.5 Defined by
users
01.10 Decel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0 5.0 5.0
01.12 Decel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec
10.0
3.0 3.0 The elapsed
deceleration
time before
the inverter
stops when
the pressure
reaches the
setting value.
Parameter Function Setting
Factory
Setting
End
user’s
master
End
user’s
slave
Note
02.00
Source of First
Master Frequency
Command
0: Digital keypad UP/DOWN keys or
Multi-function Inputs UP/DOWN. Last
used frequency saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI
3: RS-485 (RJ-45) communication
4: Digital keypad potentiometer
0 2 2
Defined
by users
02.01
Source of First
Operation
Command
0: Digital keypad
0 0 0
Defined
by users
1: External terminals. Keypad
STOP/RESET enabled.
2: External terminals. Keypad
STOP/RESET disabled.
3: RS-485 (RJ-45) communication.
Keypad STOP/RESET enabled.
4: RS-485 (RJ-45) communication.
Keypad STOP/RESET disabled.
