Delta AS Series User Manual

 UB-10-ID32A
113
87
53.6
3
2
1
4
Unit: mm
Number
Name
Description
1
UB-10-ID16A: 20-pin ML connector
UB-10-ID32A: 40-pin ML connector
Connects the external terminal module and a
wiring module
2 Terminals Input/Output terminals for wiring
3 Clip Hangs the external terminal module on a DIN rail
4 Set screw Fixes the base
4. AS332T-A/AS64AN02T-A and the external terminal modules UB-10-ID16A, UB-10-OR16A, and UB-
10-OT32A.
 UB-10-ID16A
67.0
87.0
53.
6
2
1
7
6
Unit: mm
 UB-10-OR16A
7
6
113
87
55.3
1
3
4
5
2
Unit: mm
