AX-Series Motion Controller Instructions Manual Chapter 2
488
bExecute=TRUE + FB is busy
bBusy bExecute=TRUE + FB is generating curve key points

bExecute=FALSE

bExecute=TRUE + FB is error
bExecute=TRUE + FB is done
bError bExecute=TURE + FB raise error code(non-zero)

bExecute=FALSE

bExecute=TRUE + FB is busy
bExecute=TRUE + FB is done
 Timing Diagram
 Inputs/Outputs
Name Function Data Type Setting Value Timing to Take Effect
-
-
-
-
-
 Function
 To generate key-points information for Servo Press coin mode, the data should be entered into
DMC_SP_CamCurveWrite.
 Invoke DMC_SP_CamCurveWrite to generate and write ECAM table after this FB is done.
 Coin Curve Setup Page:
 Troubleshooting
When error happens, bError will be True and dwErrorID will show non-zero. Refer to the following table for your next step.
