10
1. Basic Operation
Milling Machine Display
Built-in Panel Display
Operation button
ERROR Flashes when an error has occurred.
PAUSE
Illuminates when operation is paused. Flashes when operation is ongoing (from the point
when the operation button is pressed during milling to the point when operation is paused).
POWER Lights when the power is turned on.
CANCEL
Flashes when data is being cancelled and during the initial operations.
Milling data received while this light is ashing will be cancelled.
Operation button
Flashes during the initial operations and when mechanisms near the spindle unit are
operating. Lights under any other status while the power is on.
During
milling
Press
Pauses or resumes operation. Clears some errors.
"
Hold
Aborts milling or clears some errors.
"
During
standby
Press Rotates the rotary axis by 180 degrees.
Hold
Clears some errors (when an error has occurred).
"
