Machine Problems
136
5. Troubleshooting
Automatic Correction Fails
Check Action Refer to
Are any of the following correction
parts dirty?
• ATC magazine correction jig
• Rotary axis correction jig
• Detection pin for correction
• Milling bur sensor tip
Clean any correction parts that are dirty. Fouling due to
buildup of milling waste or the like on any of these may
impede correct sensor operation, making correct detection
impossible.
—
Is the ATC magazine correction jig
or the rotary axis correction jig
properly attached?
Verify that the ATC magazine correction jig or the rotary axis
correction jig is properly attached.
—
Collet Maintenance Cannot Continue Due to an Error Occurring
Check Action Refer to
Is anything caught on the spindle
unit or rotary axis unit?
Check whether something has become caught and is
impeding the initial operations.
—
Did you forget to attach the collet? Use the emergency release function in VPanel, and then
attach the collet.
"
To Next Page
