5. Troubleshooting
Responding to Error Messages
Error Message List
This section lists the error messages that are displayed in VPanel� If the action described here does not correct the problem or if
an error message not described here appears, contact your authorized Roland DG Corporation dealer�
Error number Message Action Error level
1000-**** The % limit switch was not found.

Level 3
1006-02** The % axis position has been shifted.

Level 2
101C-0000 The milling bur sensor was not found.

Level 3
101D-000* The % milling bur cannot be released.

Level 2
101D-010*
The % milling bur cannot be released. It might be broken from the root.

101E-000* The % milling bur might be broken.

101F-000* The % milling bur chucking has slipped out.

1020/1021-000* The % milling bur is too long/too short.

Level 1
1022-000* The % milling bur was not found.

1023-0000
1024-0000
1025-0000
1026-0000
1027-0000
1028-0000
Milling data error.

Level 2
1029-0000 The spindle experienced an overload.

Level 3
102A-000* The spindle experienced overcurrent.

102B-0000 The spindle motor temperature is too high.

102E-0000 The mechanical part has collided.

1033-000* The coolant has run out.

Level 1
1034-0000 The coolant tank is not installed.

1038-0000 Milling data error. No milling bur is selected.

Level 2
103A-000* DANGER!! The coolant is leaking!!

Level 3
103B-0000 The automatic correction is not yet nished.

Level 2
103D-0000 Milling data error. The milling bur cannot reach the milling position.

105E-0000 The pressure of the compressed air is too high or low.

Level 1
****-**** An unknown error occurred.

Level 3
Error level
Level 1
This is an error that is not very serious. After the cause of the error is eliminated, milling can resume from
the point where it stopped.
Level 2
This is an error that is moderately serous. After the cause of the error is eliminated, milling can be
restarted from the beginning. It is not possible to resume milling from the point where it stopped.
Level 3
This is an error that is very serious. Before eliminating the cause of the error, it is necessary to turn the
power o󰀨.
