2. Milling
Following Daily Operations
Collet Maintenance, Cleaning of Dummy Pin, and Checking of Coolant Flow Rate
Be sure to perform the following tasks after daily operations� These tasks are necessary for maintaining a favorable machine
condition and for ensuring a high level of product quality�
If these tasks are not executed, a message prompting operation will be displayed in VPanel�
Required Tools
Included items
Commercially
available item
Collet replacement jig Collet tap Taper cleaner Collet brush Grease Clean, dry cloth
1.
Remove the collet.
A
Open the front cover.
B
Remove the workpiece, rotary axis correction jig, and magazine correction jig.
C
Close the front cover.
D
Show VPanel.
" P. 6 "Displaying VPanel"
E
Select the machine to operate.
F
Click .
