Extended Periods of Non-Use / Moving the Machine
Draining the Coolant Lines
Drain the uid collected in the coolant lines running through the machine�
Situations Requiring This Work
• When there are no plans to use the machine for 1 week or longer (or when the machine has not been used for 1 week or
longer)
• Before moving the machine (especially when it is possible that coolant has spilled)
Required Tools
Commercially
available item
Tray
Draining
1.
Drain the coolant.
A
Remove the workpiece, milling burs, correction jigs, and other such items attached to the machine.
Important
Do not remove the dummy pin held by the spindle�
B
Open the bottom cover.
C
Pull out the coolant tank.
Important
Move the coolant tank slowly� Forcefully moving the coolant tank may cause the coolant to spray out�
88
3. Maintenance
