Email Notication Settings
123
4. Useful Functions
E
Refer to the following table and enter the items.
Item Setting details
Receiver address
Enter the receiver's email address. You can enter multiple addresses by separating them with
commas.
Sender address
Enter the sender's email address. Enter the email address used on the computer on which
VPanel is installed.
Server host name
Enter the name (SMTP server name) of the outgoing mail server for the email address entered
for the sender's address.
Server port number
Enter the port number of the outgoing mail server for the email address entered for the sender’s
address.
Use SSL connection
Select this check box to use a security-protected connection (SSL). Select or clear this check
box according to the settings of the outgoing mail server for the email address entered for the
sender’s address.
Use SMTP
authentication
Select this check box to perform authentication before sending emails. Input the user name
and password for authentication. Select or clear this check box according to the settings of the
outgoing mail server for the email address entered for the sender’s address.
F
Determine when to send notications.
You can select to send notications in the following situations.
• Milling nished
• An error has occurred.
• Maintenance nished
G
Perform a sending test.
Click [Send test] to send a test email. If the settings have been congured correctly, the following email will be
received at the address entered in [Receiver address].
• Subject: (Machine name)
• Body: Test
* If the email fails to send, the message [The email could not be sent�] will be displayed in VPanel� Check the content in the
input elds again�
Important
* It may be impossible to send emails because of the settings of security software or similar programs� If emails cannot be
sent, check the settings of the security software being used as anti-virus software or for a similar purpose�
* For detailed information about the email settings, consult your network administrator�
* VPanel does not support SMTP over SSL (SMTPs)�
