2.
Attach the retainer inside the front cover.
A
Make sure the front cover is closed, and turn o the power.
B
Open the front cover.
C
Attach the retainer (small).
Attach the retainer (small) by pushing it into the area behind the rotary axis unit.
D
Attach the retainer (large).
Attach the retainer (large) by moving it in the order indicated with (1) and (2).
1
2
Important
Be careful not to pinch the silicone portion around the spindle head with the retainer� Doing so may weaken the secureness of
the retainer�
E
Close the front cover.
Extended Periods of Non-Use / Moving the Machine
94
3. Maintenance
