C
Set the disk workpiece into the adapter base.
D
Attach the adapter cap.
1 Orient the adapter cap removed in step
B
as shown in the following gure.
Starting Milling
35
Chapter 2 Milling
Disk workpiece
Adapter base
Align the
notched part on
the right side.
