A
Use a torque screwdriver to loosen the screws holding the pin-type workpiece in position.
MEMO
Use the included spare screws when a screw is lost or worn.
B
Mount the pin-type workpiece on the pin-type workpiece adapter.
Make sure the recessed portion of the pin-type workpiece is oriented downward, align the recessed
portion with the protrusion of the pin-type workpiece adapter, and then insert the workpiece all the way in.
C
Tighten the screws using a torque screwdriver.
Tighten the screws until they click into place.
Starting Milling
42
Chapter 2 Milling
