3 Tighten the collet with the wrench while holding the detection pin with your hand.
4 Remove the detection pin and the wrench.
F
Close the front cover.
G
Click [Close collet] on the "Maintenance" tab.
Tighten the collet.
H
Click [OK].
The procedure is complete if the spindle unit moves and "The operation is completed." is displayed.
MEMO
Tightening is sucient once the wrench and
the tip of the spindle unit (the shaded portion
in the gure on the left) begin to rotate
together.
Periodic Maintenance
73
Chapter 3 Maintenance
