8 | Components description
100 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
DANGER
DO NOT MAKE THE DESCENT OR THE EXTENSION OF BOOM MOVEMENTS AS THEY ARE
AGGRAVATING MOVEMENTS FOR THE TIPPING.
When using the bypass key, only make the return or the slope of the telescopic boom, bringing this in
safety situation.
WARNING
When using the bypass key the anti-tipping systems are disabled.
It is mandatory to consult the capacity diagram of the machine and the equipment installed before
performing any maneuver.
Use the inclinometer and the letters on the boom to know the exact position of the load.
In these conditions do not perform aggravating movements for the stability of the machine, there is a
danger of loss of stability and tipping.
NOTICE
The bypass function is performed by a key to give the possibility to the Safety Officer to extract the key to
prevent deactivating the anti-tipping system during normal working conditions.
